Aventon Soltera 2.5

Model Soltera 2.5 Ebike
Weight 46 lbs
Total Weight Limit 300 lbs
Rider Height S 5'1"-5'5", M 5'5"-5'9", L 5'10"-6'2"
Box Size 59 x 11 x 33
Ebike Class Class 2
Ebike Water Resistance IPX4
Safety Certifications UL and TUV Safety Certified UL 2849 / UL 2271
Battery Safety Certifications Certified to UL 2271
Range Up to 46 Miles
Ideal Use Urban Riding
Pedal Assist 4 Levels
Frameset

Frame 6061 Double-Butted Aluminum Alloy with Internal Battery
Fork AE-E09 Soltera AL fork
Rear Spacing 142mm
Fork Spacing 100mm
Frame Style Step-Over

Wheelset
Front Wheel 700c, 36-spoke, double-wall aluminum rim, black finish, with a nutted hub drive motor, 13g stainless steel spokes (267mm NDS/269mm DS), Presta valve.
Rear Wheel 700c, 36-spoke, double-wall aluminum rim, black finish, with a nutted hub drive motor, 13g stainless steel spokes (243mm NDS/242mm DS), Presta valve.
Tires
Kenda K1085 700x38C

Ebike System
Speed Class 2
Motor 36V, 350W sustained, 540W peak brushless hub motor
Motor Torque 45Nm
Display Aventon BC280
Battery Removable Internal Lithium-ion 36V,9.6Ah(345.6Wh) with LG Cells
Battery Weight 4.14 lbs
Controller 36v 15A
Throttle Aventon LH Handlebar Mounted
Sensors Double Sided Bottom Bracket Torque Sensor
Charger 36V, 2 amp fast charger
Charging time from 0% to 100%4-5 Hours
Lights Front and rear lights integrated

Brakes

Front Brake Rotor 180mm 6 bolt
Rear Brake Rotor180mm 6 bolt
Front Brake Tektro HD-T280 Hydraulic disc brake w/o e-cutoff
Rear Brake Tektro HD-T280 Hydraulic disc brake w/o e-cutoff

Drivetrain
Rear Derailleur Shimano Tourney RD-TY300D 7 speedShift LeverShimano 7 speed twist RevoShift
Chain 7/8 speed 110 link
Freewheel Shimano MF-TZ500-7 Freewheel, Speed : 7, 14-28T
Chainring 48T
Chainring BCD130
Crankset 3pc, 170mm crank arm
Bottom Bracket Square Taper, Sealed, Dual-Sided Torque Sensor
Pedals 9/16" Alloy Platform

Cockpit
Seatpost Aventon 27.2Seat
Clamp Aventon 31.8
Handlebars Aluminum 31.8mm, 620mm
Grips Lock on grips with twist shift
Headset Aventon headset with integrated cable routing
Saddle Aventon Saddle
Included Accessories Kickstand Included, rear mount

Technical Overview

Soltera 2.5 ships as a Class II ebike, with pedal assist and throttle. Soltera 2.5 will also operate with the throttle unplugged and removed, should you want to ride in an area where throttles are prohibited.Aventon ebikes are built to the IPX4 water-resistant standard. IPX4 means that your bike is resistant to water splashes from any direction. This means it’s OK to ride your ebike in light rain. It won’t be harmed by spray from a wet road or raindrops. Your ebike is not intended to be exposed to prolonged rain, be submerged, or subjected to a pressurized spray. Don’t use a pressure washer or sprayer to clean your ebike.*Max range determined using PAS Eco throughout flat terrain with a rider weight of 160 lb.
